· 0.75” x 0.93” window opening (ID)
· Secured tabs and cable tie locking provision
· Pull to open for ease of installation
· Rigid housing case with durable UL 94V-0 plastic
· 6ft black/white twisted pair wire leads— 22AWG
· Phoenix style and other connectors (option)
· Standard Input Current 50-300A
· Available Current Outputs @ 20mA, 40mA & 100mA or
· Available Voltage Outputs @ 0.333V, 1V & 2V
· Frequency 50Hz — 400Hz
· Custom design Turns-Ratio available
· Standard accuracy 0.5
· Approximate weight 0.23Lb
· Clamping voltage on selected models
· ANSI C57.13 and C12.20 Standards
· UL materials and ETL approved
Click below to view our datasheet regarding the WC3 product
