· 0.72” x 0.62” window opening (ID)
· Secured latch for easy installation
· Swing open by pulling on tab
· Rigid housing case with UL 94V-0 durable plastic
· 6ft black/white twisted pair wire leads— 22AWG
· Keying hole for locking or service tag
· Phoenix style and other connectors (option)
· Standard Input Current 20-100A
· Available Current Outputs @ 20mA 40mA & 100mA or
· Available Voltage Outputs @ 0.333V, 1V & 2V
· Frequency 50Hz — 400Hz
· Custom design Turns-Ratio available
· Standard accuracy 0.5
· Approximate weight 0.27Lb
· Clamping voltage on selected models
· ANSI C57.13 and C12.20 Standards
· UL materials and ETL approved
Click below to view our datasheet regarding the WC1 product
