· 2.0” x 3.5” window opening (ID)
· Keying holes for locking or service tag
· Secured double latches per side
· Built-in tabs for easy removal and installation
· Rigid housing case with UL 94V-0 durable plastic
· Ergonomically designed with no exposed metal
· 8-32 screw terminals (Type A)
· Pigtail black/white wire leads (Type B)
· Standard Input Current 200-1000A
· Available Current Outputs @ 0.02A, 0.04A, 0.1A, 1A & 5A
· Available Voltage Outputs @ 0.333V, 1V & 2V
· Frequency 50Hz — 400Hz
· Custom design Turns-Ratio available
· Standard accuracy 0.5 (Varied by models)
· Approximate weight 1.7Lbs
· Clamping voltage on selected models
· ANSI C57.13 and C12.20 Standards
· UL materials and ETL approved
Click below to view our datasheet regarding the WC5 product
