· 1.3” x 1.7” window opening (ID)
· Secured latch & keying hole for locking or service tag
· Swing open for ease of installation
· Rigid housing case with UL 94V-0 durable plastic
· 6ft black/white twisted pair leads— 16 or 18AWG
· Phoenix style and other connectors (option)
· Standard Input Current 100-400A
· Available Current Outputs @ 0.02A, 0.04A, 0.1A, 1A & 5A
· Available Voltage Outputs @ 0.333V, 1V & 2V
· Frequency 50Hz — 400Hz
· Custom design Turns-Ratio available
· Standard accuracy 0.5
· Approximate weight 1.1Lbs
· Clamping voltage on selected models
· ANSI C57.13 and C12.20 Standards
· UL materials and ETL approved
Click below to view our datasheet regarding the WC4 product
